Electrical

Rated Voltage (U_r):
3 x 230 (400) V
Voltage Range:
50 … 400 V
Rated Current (I_n):
5 A
Maximum 6 A
Frequency (f):
50 … 60 Hz
Power Consumption (@P_cons):
10 V·A

Material Compliance

RoHS Declaration:
EU Declaration of Conformity M4M20-M MODBUS M4M30-M MODBUS M4M20-M ETHERNET M4M30-M ETHERNET
RoHS Information:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date:
20250314
REACH Information:
No data - If REACH inform is not yet available for a certain product
Conflict Minerals Reporting Template (CMRT):
Conflict Minerals Reporting Template
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Environmental

Ambient Air Temperature:
Operation -25 ... 70 °C
Degree of Protection:
IP54

Dimensions

Width in Number of Modular Spacings:
5.5
Product Net Width:
96 mm
Product Net Height:
96 mm
Product Net Depth / Length:
77 mm
Product Net Weight:
341 g

Ordering

Package Level 1 Units:
box 1 piece
Package Level 1 Gross Weight:
0.606 kg
E-Number (Finland):
6701085
E-Number (Norway):
8002560

Certificates and Declarations

Declaration of Conformity - CE:
EU Declaration of Conformity - M4M 30 - M4M 20 - M4M 2X

Installation

Instructions and Manuals:
User Manual M4M 30
Mounting Type:
Front Panel

Popular Downloads

Data Sheet, Technical Information:
M4M Meter brochure

External Classifications and Standards

ETIM 9:
EC001506 - Kilowatt-hour meter
ETIM 10:
EC001506 - Electricity meter
eClass:
V11.0 : 27142316
Object Classification Code:
P
